224-310KW康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯并网发电用打着机然油金钱性好: 较为先进的然油操控系統，独具的STC、ESTC 等级操控系統，个性化设定的连杆上方复燃室，进行高压喷洒于然油，加以吸雾，复燃加以。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯并网发电用汽车发起因瞬态的性能比较好: 非凡的汽车发起因综合设计制作，密切配合康明斯特别的EFC系统软件，调节的精密较高，积极地响应时段快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯电站用汽车发心理升工作电压高: 产品 方案紧凑型.外观形状布置准备合理的，作业有序。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷型号规格 QSNT. QSK19. QSK38. QSK50充分考虑中国国家非旅程3.一阶段及中美洲Tier2. Tier 3尾气排放标准法律法规规范。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零配件可知性好， 启思想操作及维持清洗保养便于，制造费低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

工率区间 Power Range   224-310KW技术要求 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观尽寸 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净质理 Dry Weight   940kg

224-310KW康明斯发电量用起主观因素的亮点：体积大概小， 压解比较高， 隔栅氧气受热，也容易加载，运动车载电子电源模块的选择。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

启倾向款式	通常用最大功率(kW)Prime Power	自备热效率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
